| Business Type | Manufacturer, Supplier |
| Warranty | 1 Year |
| Type | HELICAL GEARMOTOR |
| Shape | Cylindrical |
| Click to view more | |
Product Details
Driven Type
Electric
Finishing
Polished
Material
Cast Iron
Brand Name
Anubhuti
Country of Origin
India
Power
0.37 KW TO 3.7 KW
Phase
Three Phase
Ambient Temperature
55 C
Surface treatment
60 C
Rated Speed
1440 RPM
MODEL
APS 102 TO APS 185
Mounting
B3 / B5
Hourspower
0.5 HP TO 5 HP
RATIO
3.8:1 TO 45:1
Product Code
aps004
Port
X FACTORY
Payment Terms
T/T, Other
Delivery Time
READY STOCK
Packaging Details
BOX
GEAR BODY :- It is made of close grain cast iron, which is absolutely dust proof & oil tight.
GEARS :- Gears are helical type-made of cast iron, hardened alloy steel, Gear teeth are hobbed and profile ground for smooth & silent running.
OIL SEAL:- Silicon oil seals are used to resist very high temperature resulting from the heaters on the barrel.
BEARING :- Taper roller bearings of ample capacity are used to withstand thrust and radial loads.
LUBRICATION :- Lubrication is done by splash of oil, no separate care is required except periodic checking of oil level
– Use proper grade of gear oil only.
– Change first filling of oil after two months of operation and them after every six months.
ADVANTAGES :- The Advantages of Helical inbuilt thrust housing gearbox over conventional worm gear box are :-
1. No Alignment Problem
2. Cost Savings
3. Space Savings
4. Power Savings
5. Less Maintenance
6. Easy to Assemble & Dismantle
1. No Alignment Problem
2. Cost Savings
3. Space Savings
4. Power Savings
5. Less Maintenance
6. Easy to Assemble & Dismantle
