| Business Type | Manufacturer, Supplier |
| Finishing | Noback Cast Iron |
| Power | 3.7 KW |
| Country of Origin | India |
| Click to view more | |
Product Details
Phase
Three Phase
Brand Name
ANUBHUTI
Material
Cast Iron
Shape
Round
Color
as per requirement
Automatic Grade
Semi Automatic
Speciality
Robust Construction, Easy To Use, High Efficiency, Reliable
Usage
Industrial
Certification
ISO 9001:2008
Voltage
440 V
Mounting Type
Foot
Overall Length
20-25 Inch
Type
AC
Weight
34 kg
Frequency
50 Hz
Efficiency
IE2
Warranty
1 Year
Ambient Temperature
50C
IP Rating
IP55
Number of Poles
4 Pole
Body Enclosure
IP55
Series
Cast Iron
Pole
2/4/6/8
Enclosure
IP55
Horsepower
5
Frame
112m
Product Code
APS001
Port
X FACTORY
Payment Terms
Other
Delivery Time
READY STOCK
Packaging Details
box
Ratings: All Standard Three-phase Motors are continuous rated to comply with performance standards.
Voltage and Frequency: Supply volts 415 +- 5% 3 phase 50 Hz. +- 3% (on customer request we are also able to supply motor in 220, 380, 460, 525 volts on HZ. 50 or 60)
Enclosures: Motor IP-44 Protection as defined in IS: 4691. Motors can be supplied with IP-54 and IP-55 on request.Range:Range : 0.10 H.P. to 20 H.P. (0.075 K.W. to 15 K.W.) Frame 63 to 160L in 2, 4, 6, & 8 Pole
Mounting: Foot – Flange – Face
Standards: Performance conforms to be: 325 and dimensions according to IS 1231 & IS 2223
Frame: Motor are supplied in a robust, rugged cast iron frame with integral feet. On Request, we can supply motor in aluminium body up to 100 L frame.
