| Business Type | Manufacturer, Supplier |
| Ambient Temperature | 50 Degree |
| Frequency | 50 Hz |
| Mounting Type | Foot |
| Click to view more | |
Product Details
Power
1.5 KW
Country of Origin
India
Phase
Three Phase
Brand Name
ANUBHUTI
Finishing
Polished
Shape
Round
Color
Sliver
Automatic Grade
Semi Automatic
Speciality
Robust Construction,Easy To Use,High Efficiency,Reliable
Usage
Industrial
Certification
ISO 9001:2008
Voltage
440 V
Type
AC
Weight
15kg
Warranty
1 Year
IP Rating
IP55
Corrosion Resistance
Yes
Number of Poles
4 Pole
Horsepower
2 HP
Speed
1440 rpm
Insulation Class
F Class
Frame
90L
Duty
S1
MOUNTUNG
B3 / B5 / B14
Ratings: All Standard Three-phase Motors are continuous rated to comply with performance standards.
Voltage and Frequency: Supply volts 415 +- 5% 3 phase 50 Hz. +- 3% (on customer request we are also able to supply motor in 220, 380, 460, 525 volts on HZ. 50 or 60)
Enclosures: Motor IP-44 Protection as defined in IS: 4691. Motors can be supplied with IP-54 and IP-55 on request.Range:Range : 0.10 H.P. to 20 H.P. (0.075 K.W. to 15 K.W.) Frame 63 to 160L in 2, 4, 6, & 8 Pole
Mounting: Foot – Flange – Face
Standards: Performance conforms to be: 325 and dimensions according to IS 1231 & IS 2223
Frame: Motor are supplied in a robust, rugged cast iron frame with integral feet. On Request, we can supply motor in aluminium body up to 100 L frame.
